      Star tent and star pavilion Ø 10 m

      Large-area star tent with a distinctive shape and high-quality print. Depending on the version, the tent roof is equipped with binding tape for open use or with zippers for attaching up to 6 tent walls.

      Tent roof

      • star-shaped pavilion design with 6 passage arches
      • fully printable over the entire surface using digital printing
      • Versions:
        • with binding tape: passage arches with trimming tape; use with side walls not possible
        • with zippers: passage arches with zippers; use with side walls possible

      Tent walls

      • only available with zipper version
      • selection of 1 to 6 tent walls directly within the product
      • tent walls optionally fully printed or transparent, unprinted
      • wall size per tent wall: approx. 493 × 307 cm
      • Transparent tent wall:
        • clear film, approx. 360 g/m2
        • UV-resistant and waterproof
        • can be cleaned with a damp cloth
        • bottom edge hemmed, curved top edge with zippers for attachment to the star tent, bottom edge with loops made of webbing, made of three welded panels

      Material

      • Variotex® Z SE: matte polyester fabric, UV-resistant with high lightfastness, waterproof up to a water column of 2,000 mm, seams rainproof
      • Variotex® Z SE with lamination: more scratch-resistant and durable thanks to additional protective lamination, dirt-repellent, wipeable with a damp cloth
      • clear film, approx. 360 g/m2: transparent, unprinted tent wall, UV-resistant and waterproof

      Printed parts without lamination should be handled with care to avoid scratches. The version with binding tape is only suitable for open star pavilions without tent walls.

      • Without lamination: recommended for medium to long-term use; handle printed surfaces carefully to avoid scratches
      • With lamination: additional protective layer for high scratch resistance, dirt-repellent surface and extended durability

      System

      • 5-part aluminium mast (Ø 76 mm) with base plate and fastening accessories
      • crank system for precise adjustment and optimal tensioning of the roof
      • end cap made of die-cast aluminium
      • base plate made of aluminium
      • 6 ground stakes (Ø 18 mm, length approx. 550 mm) for anchoring the covering
      • transport bag made of vinyl tarpaulin with pull loop
      • pre-assembled on the tent roof: steel ring for fixing the tent peak and aluminium cast shoes for securing the covering

      Size & weights

      Feature Value
      Size Ø 10 m
      Total height approx. 500 cm
      Passage height approx. 210 cm
      Base area approx. 78.54 m2
      Weight frame approx. 14 kg
      Weight tent roof (with shoes) approx. 16 kg
      Weight per tent wall approx. 1.9 kg
      Wall size per tent wall approx. 493 × 307 cm

      All dimensions and weights are approximate; technical changes and tolerances reserved.

      Scope of delivery

      • aluminium mast (Ø 76 mm) incl. base and fastening accessories, packed in a transport bag made of vinyl tarpaulin with pull loop
      • 2 measuring tapes
      • ground stake puller
      • tent roof and selected tent walls

      Use

      • suitable for events and outdoor use
      • must always be securely anchored to the ground
      • not tested for wind and snow loads
      • do not use in adverse weather conditions such as strong wind, rain or snow
      • do not use open flames or heating devices with open fire
      • classified as temporary structures; official approval may be required
      • please observe the complete safety instructions in the documentation
