- Description
-
Print details
- Digital printing in brilliant colors
- UV-resistant, excellent lightfastness (6–7)
- Spot colors available
Tent wall with door
Sidewall with roll-up door: This tent wall protects against wind and weather, is fully printable, and is ideal as a large-scale advertising space – with convenient access via door.
Compatible with:
- Folding tent Eco, Basic, Select, and Premium
Material
Matte polyester fabrics in two qualities are used. Both materials ensure excellent color reproduction.
Property Variotex® Z SE Variotex® S SE Fabric Weight 200 g/m² (without lamination)
220 g/m² (with lamination)270 g/m² (without lamination)
290 g/m² (with lamination)Flame Retardancy EN 13501-1 / B-s1, d0 EN 13501-1 / B-s2, d0 Tensile Strength longitudinal 1200 N, transverse 1000 N longitudinal 2000 N, transverse 1200 N Water Column 2,000 mm 2,000 mm Characteristics dense, fine-threaded heavy, robust All measurements are approximate; subject to technical changes and tolerances.
- Without lamination: recommended for medium- to long-term use; handle printed parts without lamination with care to avoid scratches
- With lamination: recommended for long-term use and frequent location changes; the additional protective lamination after printing provides a scratch-resistant, dirt-repellent, and particularly durable surface
Design features
- Hemmed all around
- Top edge on both sides with hook-and-loop tape for double-sided fastening to the valance
- Side edges optionally:
- With 5 fastening loops each
- With 5 fastening loops and zipper – for enhanced wind and weather protection
- Roll-up door made of tent fabric, opens and closes via two double zippers operable from both sides
- The wall can be attached with the printed side facing in or out. (Note: For multiple zippered tent walls, only one consistent print orientation is possible.)
Sizes & variants
Tent Wall Size Door Variants Door Size (W × H) 300 × 205 cm 1 door, center 0.8 × 2.05 m 450 × 205 cm 1 door, center 0.8 × 2.05 m 1 door, left 0.8 × 2.05 m 1 door, right 0.8 × 2.05 m 600 × 205 cm 1 door, left 0.8 × 2.05 m 1 door, right 0.8 × 2.05 m 400 × 220 cm 1 door, left 0.8 × 2.20 m 1 door, right 0.8 × 2.20 m 1 door, center 0.8 × 2.20 m 600 × 220 cm 1 door, left 0.8 × 2.20 m 1 door, right 0.8 × 2.20 m 1 door, center 0.8 × 2.20 m 800 × 220 cm 1 door, left 0.8 × 2.20 m 1 door, right 0.8 × 2.20 m 1 door, left side 0.8 × 2.20 m 1 door, right side 0.8 × 2.20 m Dimensions (W × H)
- 300 × 205 cm: suitable for tent sizes 3 × 3 m; 3 × 4.5 m; 3 × 6 m
- 450 × 205 cm: suitable for tent size 3 × 4.5 m
- 600 × 205 cm: suitable for tent size 3 × 6 m
- 400 × 220 cm: suitable for tent sizes 4 × 4 m; 4 × 6 m; 4 × 8 m
- 600 × 220 cm: suitable for tent size 4 × 6 m
- 800 × 220 cm: suitable for tent size 4 × 8 m
