Star tent Ø 10 m with side walls
With the star tent Ø 10 m you buy a compact solution for attention-grabbing promotion areas, smaller events and flexible outdoor uses. The characteristic shape, the full-surface printable roof area and the choice between open canopy variant or version with up to 6 tent walls combine advertising effect with reliable protection outdoors.
Tent roof
- Star-shaped canopy with 6 passage arches
-
Variants:
- Canopy variant: passage arches equipped with trimming tape; use as canopy without side walls
- Tent variant: passage arches equipped with zippers; for use as tent with side walls
The tent variant can be used both with and without tent walls. In the canopy variant, a later equipping with side walls is not possible.
Tent walls
- For tent variant (with zippers)
- Selection from 1 to 6 tent walls
- Size per tent wall: approx. 493 × 307 cm
- Curved upper edge with zipper for fastening to the star tent
- Lower edge hemmed, with loops made of webbing
- Printed tent walls:
- Full wall or side walls with different window variants or entrance
- Completely individually printable (except window areas)
- Transparent tent wall:
- Full wall made of transparent clear film (without print)
- Made from three welded panels
- Further side walls can be found in our category tent walls for star tent.
Materials
- Variotex® Z SE: matte polyester fabric, UV-resistant (lightfastness 6-7), waterproof (water column 2,000 mm), seams rainproof, flame-retardant (EN 13501-1 / B-s1, d0)
- Without lamination, approx. 200 g/m2: recommended for medium to long-term uses; print parts without lamination should be handled carefully to avoid scratches
- With lamination, approx. 220 g/m2: recommended for long-term use and frequently changing locations; the additional protective laminate ensures a very scratch-resistant, dirt-repellent and particularly durable surface, wipeable with a damp cloth
- Clear film, approx. 360 g/m2: transparent PVC film, UV-resistant and waterproof, wipeable with a damp cloth, unprinted
System
- 5-part aluminium mast (Ø 76 mm) with base plate and fastening accessories
- Crank system for fine adjustment and for perfect tensioning of the roof
- End cap made of aluminium cast
- Base plate made of aluminium
- 6 ground pegs, Ø 18 mm, length approx. 550 mm, for anchoring the covering in the ground
- Transport bag made of tarpaulin with pull loop
- Preassembled on the tent roof: steel ring for fixing the tent top and shoes made of aluminium cast for lower fixing of the covering
Sizes & weights
| Feature |
Value |
| Size |
Ø 10 m |
| Total height |
500 cm |
| Passage height |
210 cm |
| Base area |
78.54 m2 |
| Weight frame |
14 kg |
| Weight tent roof (with shoes) |
16 kg |
| Weight per tent wall |
1.9 kg |
| Wall size per tent wall |
493 × 307 cm |
All dimensions and weights are approximate values; technical changes and tolerances reserved.
Scope of delivery
- Complete set:
- Aluminium mast (Ø 76 mm) incl. base plate and fastening accessories, packed in a transport bag made of tarpaulin with pull loop
- 2 measuring tapes
- Ground peg puller
- Tent roof and selected tent walls
- 6 tent shoes made of aluminium cast
- Roof only:
- Printed tent roof
- 6 tent shoes made of aluminium cast
- Tent frame only:
- Aluminium mast (Ø 76 mm) incl. base plate and fastening accessories
- Packed in a transport bag made of tarpaulin with pull loop
Use
- Suitable for events and uses in the outdoor area
Safety instructions
- Star tents and star canopies must always be securely anchored to the ground
- Not tested for wind and snow loads; do not use in adverse weather conditions such as strong wind, rain or snow
- Open fire as well as heating devices with open flames must not be used
- Star tents and star canopies belong to the temporary structures; for use, an execution permit from the responsible building authority is required
- Please note the complete safety instructions for this product.
